TP-Link Jetstream TL-SG3428 V2 29-Port L2+ Managed Switch
Key Specification
‣ Type
- Network Switch
‣ No. of Port - 29 (24 × 10/100/1000 Mbps
RJ45 ports, 4 × Gigabit SFP slots)
‣ PoE
- No PoE support
‣ Network Standards - IEEE 802.3,
IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad, IEEE 802.3af/at, IEEE
802.1Q, IEEE 802.1p, IEEE 802.1x
‣ Data
Transfer Rate - 10/100/1000 Mbps per port
‣ Form
Factor - Desktop or wall-mountable
Product Specification
|
Specification |
Details |
|
Brand |
TP-Link |
|
Model |
TL-SG3428 V2 |
|
Type |
JetStream
29-Port L2+ Managed Switch |
|
Product Number (P/N) |
TL-SG3428 V2 |
|
Ports |
24
× Gigabit RJ45, 4 × Gigabit SFP, 1 × RJ45 Console, 1 × Micro-USB Console |
|
Switching Capacity |
56 Gbps |
|
Forwarding
Rate |
41.66
Mpps |
|
MAC Address Table |
16K entries |
|
Packet
Buffer Memory |
12
Mbit |
|
Jumbo Frame Support |
Up to 9 KB |
|
Management |
Web
GUI, CLI, SNMP, RMON, Omada SDN Integration |
|
Layer 2+ Features |
VLAN, Static Routing, Port Mirroring, STP/RSTP/MSTP, LACP,
802.3x Flow Control |
|
Security
Features |
802.1X
RADIUS, IP-MAC-Port Binding, Port Security, DoS Defend, Storm Control, DHCP
Snooping |
|
Multicast Management |
IGMP Snooping, IGMP Throttling & Filtering |
|
Power
Supply |
100–240
V AC, 50/60 Hz |
|
Power Consumption |
19.9 W (220 V/50 Hz) |
|
Heat
Dissipation |
67.73
BTU/hr (220 V/50 Hz) |
|
Form Factor |
Rackmountable |
|
Cooling |
Fanless |
|
Dimensions |
440 × 180 × 44 mm |
|
Weight |
~2.1
kg |
|
Warranty |
5 years |
Product Details
TP-Link JetStream TL-SG3428 V2
29-Port L2+ Managed Switch
The TP-Link JetStream TL-SG3428
V2 is a high-performance 29-port L2+ managed switch designed for enterprise
networks, business offices, and campus environments. Equipped with 24
Gigabit RJ45 ports and 4 Gigabit SFP slots, plus 1 console port,
it delivers high-speed connectivity, advanced routing, and enterprise-grade
management features. With robust L2/L2+/L3 Lite capabilities, comprehensive
security, and intelligent traffic management, this switch ensures scalable,
secure, and reliable networking.
Key Features & Benefits
- 29 Ports Total
– 24 × Gigabit RJ45 ports, 4 × Gigabit SFP slots, 1 × Console
port.
- High Switching Capacity – Up to 56Gbps backplane bandwidth.
- Advanced L2+ & L3 Lite Features – Supports static routing, VLAN, QoS, IGMP
Snooping, Link Aggregation.
- Enterprise Security
– Features 802.1Q VLAN, ACLs, DoS protection, port security, and DHCP
snooping.
- Efficient Management
– Supports Web, CLI, SNMP, and Cloud management via Omada SDN.
- Traffic Optimization
– Advanced QoS and bandwidth control ensure smooth performance for
voice, video, and critical data.
- Stackable & Scalable – Ideal for growing business networks.
- Durable & Reliable Build – Metal rack-mount design for continuous operation.
Specifications
- Model:
TL-SG3428 V2
- Type:
29-Port L2+ Managed Gigabit Switch
- Port Speed:
10/100/1000Mbps (auto MDI/MDIX)
- Ports:
24 × RJ45, 4 × SFP slots, 1 × Console port
- Switching Capacity:
56Gbps
- Forwarding Rate:
41.7 Mpps
- Management Options:
Web, CLI, SNMP, RMON, Omada SDN
- Security Features:
802.1Q VLAN, ACLs, DHCP snooping, DoS defense, Storm control, 802.1X
authentication
- Traffic Management:
QoS, IGMP Snooping, Link Aggregation, Port Mirroring
- Form Factor:
Rack-mount metal chassis
- Color:
Black
Why Choose TP-Link TL-SG3428 V2?
- Combines enterprise-level performance, security, and
management.
- Provides advanced L2+ and static routing for
optimized traffic flow.
- Perfect for medium to large business networks, ISPs,
and campus deployments.
Shop Now at Computer Village Agrabad
Get the TP-Link JetStream TL-SG3428 V2 29-Port L2+ Managed Switch at Computer
Village Agrabad, Wali Mansion, 600 Sk. Mujib Road, Chowmohoni, Agrabad,
Chattogram.
We provide fast delivery across Bangladesh, including Dhaka,
Chattogram, Sylhet, Rajshahi, Khulna, and Barisal.
