Tenda TEG1118P-16-250W 18-Port Unmanaged PoE Switch
Key Specification
‣Ports: 16
× 10/100/1000 Mbps RJ-45 (PoE+) + 2 × Gigabit SFP
‣PoE: IEEE
802.3af/at; up to 30 W per port; total PoE budget 230 W
‣Network Standards:
IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x
‣Performance:
Switching capacity 36 Gbps
‣Form Factor:
Rack-mountable; dimensions 440 × 179.6 × 44 mm; input voltage 100–240V AC,
50/60Hz
Product Specification
|
Category |
Details |
|
Brand
/ Model / P/N |
Tenda
TEG1118P-16-250W |
|
Type |
Unmanaged PoE Gigabit Switch |
|
Ports
& Slots |
•
16 × 10/100/1000 Mbps RJ-45 ports (with PoE) • 2 × 1000 Mbps SFP slots
(uplinks) |
|
PoE Support / Power |
• Compliant with IEEE 802.3af & IEEE 802.3at • Max PoE
power per port: 30 W • Total PoE power budget: ~230 W • Max power consumption
of switch: ~250 W |
|
Technical
/ Switching Data |
•
Backplane bandwidth: ~36 Gbps • MAC address table: 8K entries • Forwarding
mode: Store-and-forward • Supports 4 operating “modes”: Standard, Priority,
Extend, VLAN • Lightning / surge protection (~6 kV) • LED indicators:
Link/Act per port, SFP LEDs, Power LED, PoE-MAX LED |
|
Physical / Environmental |
• Dimensions: ~440 × 179.6 × 44 mm • Operating
temperature: 0-45 °C • Storage temperature: -40-70 °C • Operating humidity:
~10-90% non-condensing • Storage humidity: ~5-90% non-condensing |
|
Power
Input / Voltage |
100-240
V AC, 50/60 Hz |
|
Other Features |
• Auto MDI/MDIX • Flow control: full-duplex (802.3x), half
duplex backpressure • Modes to adjust behavior (e.g. Extend to increase
distance; VLAN mode to isolate ports; Priority to give certain ports
priority) |
* Product may vary with different Kit or
Version
Product Details
Tenda TEG1118P-16-250W 18-Port Gigabit
Unmanaged PoE Switch
The Tenda TEG1118P-16-250W is
a high-performance 18-port Gigabit unmanaged PoE switch designed for SMBs,
surveillance systems, and wireless networking deployments. It features 16
Gigabit RJ45 PoE+ ports, 2 Gigabit uplink ports (1 RJ45 + 1 SFP),
and a 250W PoE power budget, making it ideal for powering IP cameras,
access points, and VoIP phones. With plug-and-play installation, long-distance
transmission mode, and robust surge protection, this switch ensures reliable,
efficient, and cost-effective networking.
Key Features & Benefits
- 18 Ports Total
– 16 × Gigabit PoE+ RJ45, 1 × Gigabit RJ45 uplink, 1 × Gigabit
SFP uplink.
- High PoE Power
– Supports IEEE 802.3af/at PoE+, delivering up to 250W total PoE
budget.
- Long-Distance Mode
– Extends PoE transmission up to 250 meters for IP cameras.
- Plug & Play
– No configuration required, simple installation.
- Stable Performance
– 36Gbps switching capacity ensures smooth data transfer.
- Enhanced Protection
– Built-in 6kV lightning protection for reliable outdoor
deployment.
- Smart Features
– Includes one-key VLAN isolation for improved network security.
- Durable Design
– Rack-mountable metal housing with effective heat dissipation.
Specifications
- Model:
TEG1118P-16-250W
- Type:
Unmanaged PoE Switch
- Ports:
16 × Gigabit PoE, 1 × Gigabit RJ45 uplink, 1 × Gigabit SFP uplink
- PoE Standard:
IEEE 802.3af/at
- PoE Power Budget:
250W total
- Switching Capacity:
36Gbps
- Forwarding Rate:
26.7 Mpps
- Surge Protection:
6kV lightning protection
- Form Factor:
Rack-mountable (1U) metal chassis
- Color:
Black
Why Choose Tenda TEG1118P-16-250W?
- Provides affordable PoE+ connectivity with 250W
power budget.
- Ideal for IP surveillance, Wi-Fi access points, and
small business networks.
- Offers plug-and-play operation with long-distance
and VLAN isolation modes.
Shop Now at Computer Village Agrabad
Get the Tenda TEG1118P-16-250W 18-Port Gigabit Unmanaged PoE Switch at Computer
Village Agrabad, Wali Mansion, 600 Sk. Mujib Road, Chowmohoni, Agrabad,
Chattogram.
We provide fast delivery across Bangladesh, including Dhaka,
Chattogram, Sylhet, Rajshahi, Khulna, and Barisal.
