Hikvision DS-2SE4C225MWG-E(12F0) Pan & Tilt IP Camera

The Hikvision DS-2SE4C225MWG-E(12F0) is a dual-lens, pan & tilt IP camera designed for both indoor and outdoor environments, providing advanced surveillance features. With a 2.0 MP resolution, this camera ensures high-quality video capture with color night vision and wide dynamic range for enhanced visibility in varying lighting conditions.

Camera Performance

• Sensor: 1/2.8 Inch Scan CMOS for sharp and clear images.
• Resolution: 1920 x 1080 (1080p), delivering high-definition video.
• Shutter Speed: 1s to 1/30,000s for capturing fast-moving objects.
• Slow Shutter: Yes for capturing clearer night scenes.
• Day & Night: ICR (Infrared Cut Filter Removal) for better day-night performance.
• Night Vision: Yes, with color night vision for clearer images in low light.
• S/N Ratio: >=52 dB for reduced noise in low-light conditions.

Lens & Viewing Capabilities

• Lens:
• Primary Lens: 2.8mm for wide-angle viewing.
• Secondary Lens (PTZ Channel): 4.8 to 120mm, with 25x optical zoom for detailed long-range surveillance.
• Focal Length:
• Bullet Channel: 2.8mm.
• PTZ Channel: 4.8mm to 120mm, offering flexible zoom capabilities.
• PTZ (Pan-Tilt-Zoom): Yes, for precise control of the camera’s pan, tilt, and zoom functions.
• Zoom:
• PTZ Channel: 25x optical zoom, 16x digital zoom for detailed views at various distances.
• Viewing Angle:
• Bullet: 106.1° (H), 56.8° (V), 126.5° (D).
• PTZ: 54.8° to 2.8° (H), 31.4° to 1.5° (V), 62.2° to 3.2° (D).

Image & Video Quality

• Frame Rate:
• Main Stream:
• 50 Hz: 25 fps (1920 x 1080, 1280 x 960, 1280 x 720).
• 60 Hz: 30 fps (1920 x 1080, 1280 x 960, 1280 x 720).
• PTZ Channel:
• 50 Hz: 25 fps (1920 x 1080, 1280 x 960, 1280 x 720).
• 60 Hz: 30 fps (1920 x 1080, 1280 x 960, 1280 x 720).
• Noise Reduction: Yes.
• Digital Noise Reduction (DNR): 3D DNR for clearer images in low-light settings.
• Wide Dynamic Range (WDR): 120 dB for clearer visibility in varying light conditions.

Network & Connectivity

• Ethernet Port: 1 x RJ45 self-adaptive 10M/100M Ethernet port.
• Wi-Fi: No.
• Supported Protocols:
• IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket.

Security Features

• Security:
• Authenticated username and password, MAC address binding, HTTPS encryption, 802.1X authenticated access, IP address filter.
• Password Protection: Yes.
• Watermark: Yes for added video integrity.
• Motion Detection: Yes.
• Human Detection: Yes.
• Face Detection: Yes.
• Lightning Protection: Yes.
• Surge Protection: Yes.
• Voltage Transient Protection: Yes.
• Simultaneous Live View: Up to 20 channels for multi-location monitoring.

Storage & Audio

• Card Slot: Yes, for MicroSD.
• Storage Supported: Up to 256GB.
• Mic & Speaker: No.
• Audio Communication: No.
• Input Trigger: Unmentioned.
• Working Distance: 100 meters for optimal detection range.

Physical Build & Power

• Form Factor: Dome, for discreet surveillance.
• Body Material: Aluminum (ADC12) for durability.
• Color: Black & White.
• Dimensions: 166 x 375mm.
• Weight: 2400 gm.
• Relevant Accessories: Unmentioned.

Power & Environmental Conditions

• Power Supply:
• 12VDC, PoE+ for flexible power options.
• Approx. Power Consumption: 24W (Max.).
• Operating Temperature: -30°C to 65°C.
• Operating Humidity: Lower than 90%RH.

Warranty

• 1 Year Warranty (without adapter).
