Hikvision DS-2CD1043G2-LIU (4mm) (4.0MP) Smart Hybrid Light Fixed Bullet IP Camera
Key Specification
‣ Usage - Outdoor
‣ Form-Factor - Bullet
‣ Mega Pixels (MP) - 4.0
‣ Night Vision Mode - Black
and White
‣ Working Distance – 78
Meter
Product Specification
|
Brand |
Hikvision |
|
Model |
Hikvision
DS-2CD1043G2-LIU |
|
Usage |
Outdoor |
|
Type |
IP
Camera |
|
Camera |
Number of Camera: 1 Camera Type: Fixed Mega Pixels (MP): 4.0 Max. Camera Resolution: 2560 x 1440 Secondary Camera Type: Not Applicable Secondary Camera Mega Pixel (MP): Not
Applicable Secondary Camera Max Resolution: Not
Applicable Sensor Type: 1/3 Inch Progressive Scan CMOS Resolution: Main Stream: 50Hz: 20fps (2560 x
1440), 25fps (1920 x 1080, 1280 x 720), 60Hz: 20fps (2560 x 1440), 24fps
(1920 x 1080, 1280 x 720) Shutter Speed: 1/3 s to 1/100,000 s Slow Shutter: No Day & Night: IR cut filter Night Vision: Yes Night Vision Mode: Black and White S/N Ratio: >52 dB |
|
Lens |
Number
of Lens: Single Lens (Primary) Lens: Unmentioned Focal
Length: Unmentioned PTZ: No Zoom: 25x
(Optical), 16x (Digital) Viewing
Angle: 78 Degree (H), 42 Degree (V), 93 Degree (D) |
|
Image |
Triple-Stream: Unmentioned Frame Rate - Unmentioned Noise Reduction: Yes Digital Noise Reduction (DNR): 3D DNR Wide Dynamic Range (WDR): 120 dB |
|
Network
& Connectivity |
Sim
Supported: No Sim
Network Type: Not Applicable Interface(s):
1 x RJ45 10M/100M self-adaptive Ethernet port Wi-Fi: No Wi-Fi
Details: No |
|
Security |
Security: Password protection, complicated
password, watermark, basic and digest authentication for HTTP, WSSE and
digest authentication for Open Network Video Interface, security audit log,
host authentication (MAC address) Password Protection: Yes Watermark: Yes Motion Detection: Yes Human Detection: Yes Face Detection: No Lightning Protection: No Surge Protection: No Voltage Transient Protection: No Simultaneous Live View: Up to 6 channels |
|
Technical
Data |
Video
Type: Main stream: H.265+/ H.265/ H.264+/ H.264, Sub-stream: H.265/ H.264/
MJPEG Mic
& Speaker: Only Mic Audio
Communication: No Input
Trigger: Unmentioned Working
Distance: Unmentioned Protocols:
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP,
SMTP |
|
Physical Attributes |
Form-Factor: Bullet Card Slot: No Storage Type: Unmentioned Storage Supported: Unmentioned Body Material: Metal + Plastic Color: White Dimensions: 170.8 x 66 x 69.1mm Weight (gm): 270 gm Relevant Accessories (Not Included): Unmentioned |
|
Power |
Power: 12V
DC Battery
Capacity: Not Applicable Battery
Backup: No Battery
Backup Time: Not Applicable Power
Supply: 12 VDC +- 25%, 0.4A, max. 5W, 5.5mm coaxial power plug, reverse
polarity protection, PoE: IEEE 802.3af, Class 3, max. 6.5W Approx.
Power Consumption: 6.5W Operating
Temperature: -30 Degree C to 65 Degree C Operating
Humidity: Humidity 95% or less (non-condensing) |
|
Warranty |
1 Year (Without Adapter) |
|
* Product may vary with
different Kit or Version |
|
Product Details
Hikvision
DS-2CD1043G2-LIU IP Camera
The Hikvision DS-2CD1043G2-LIU
is an advanced outdoor IP camera offering excellent 4.0MP resolution
and 2560 x 1440 maximum camera resolution, making it an ideal solution
for high-definition video surveillance.
Camera
Performance
- Sensor:
1/3 Inch Progressive Scan CMOS
- Resolution:
Main Stream: 2560 x 1440 at 20 fps (50Hz) and 1920 x 1080 at
25 fps (50Hz).
- Shutter Speed:
1/3 s to 1/100,000 s for capturing both fast and slow-moving
objects.
- IR Cut Filter:
Provides accurate color reproduction during the day and optimal black and
white night vision.
- Night Vision:
Black and White mode for clear night-time surveillance.
- S/N Ratio:
>52 dB for minimal noise in the video output.
Lens
& Viewing Capabilities
- Lens:
Not explicitly mentioned but the camera features fixed primary lens
performance.
- Focal Length:
Not explicitly mentioned.
- Zoom:
25x optical zoom and 16x digital zoom for flexible and
high-quality image zoom.
- Viewing Angles:
- Horizontal FOV:
78°
- Vertical FOV:
42°
- Diagonal FOV:
93°
Quality
- Noise Reduction:
Equipped with 3D Digital Noise Reduction (DNR) for clearer images
in low-light conditions.
- Wide Dynamic Range (WDR): 120 dB WDR ensures balanced exposure in scenes
with both bright and dark areas.
Network
& Connectivity
- Ethernet Port:
1 x RJ45 10M/100M self-adaptive Ethernet port for stable wired connections.
- Wi-Fi:
Not supported.
- Protocols:
Includes TCP/IP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, and
more for seamless integration with various networks.
Security
Features
- Password Protection:
Offers password protection, including support for complex
passwords.
- Watermark:
Supports adding a watermark for video security.
- Motion Detection:
Detects movement within the camera’s field of view for enhanced
surveillance.
- Human Detection:
Recognizes human figures for more accurate alerts.
- Face Detection:
Not supported.
Storage
- Storage Type:
No built-in storage options mentioned.
- Card Slot:
No card slot for external storage.
Physical
Build & Power
- Form Factor:
Bullet camera style for outdoor installation.
- Body Material:
Metal + Plastic combination for durability.
- Color:
White.
- Dimensions:
170.8 x 66 x 69.1 mm.
- Weight:
270 gm.
- Power Consumption:
6.5W maximum powered via 12V DC or PoE (802.3af) for
flexible installation options.
Operating
Conditions
- Operating Temperature:
-30°C to 65°C, suitable for harsh outdoor conditions.
- Operating Humidity:
Up to 95% (non-condensing), ensuring reliable performance in humid
environments.
Warranty
- Comes with a 1-year warranty (without adapter).
