Grandstream GWN7802 20-Port (16-Port 10/100/1000Mbps Ethernet & 4-Port 10/100/1000Mbps SFP) Managed Network Switch
Key Specification
‣ Type
- Network Switch
‣ No. of Port - 16 × Gigabit RJ-45 Ethernet
+ 4 × Gigabit SFP
‣ PoE
- Up to 30 W per PoE port; ~240 W total PoE budget
‣ Network Standards - IPv4/IPv6;
IEEE 802.3 /3u /3ab /3z; VLANs, QoS, 802.1Q, 802.1p; security features like ARP
inspection, IP source guard, DHCP snooping
‣ Data
Transfer Rate - ~20 Gbps non-blocking throughput; ~40 Gbps switching
capacity; ~29.76 Million packets/s forwarding rate
‣ Form
Factor - Can be rack-, wall-, or desktop-mounted; includes power supply;
fanless / quiet in some models
Product Specification
|
Category |
Details |
|
Brand |
Grandstream |
|
Model |
GWN7802 / GWN7802P (PoE version) |
|
Type |
Enterprise
Layer 2+ Managed Network Switch |
|
Ports |
16 × Gigabit Ethernet (RJ-45) ports + 4 × Gigabit SFP
uplink ports |
|
PoE
Support |
GWN7802P:
Supports PoE / PoE+ on 16 RJ-45 ports, up to 30W per port, total budget ~240W |
|
Network Protocols & Features |
IPv4, IPv6; IEEE 802.3 standards; VLAN (802.1Q, QinQ,
Voice VLAN); STP/RSTP/MSTP; QoS (802.1p); IGMP/MLD snooping; ACLs; ARP
inspection; DHCP snooping; IP Source Guard; DoS protection |
|
Forwarding
& Switching Capacity |
Throughput:
~20 Gbps non-blocking Switching capacity: ~40 Gbps Forwarding rate: ~29.76
Mpps |
|
Memory / Buffer |
Packet buffer: ~4.1 MB MAC address table: 8K entries VLAN
support: up to 4K VLANs |
|
Physical
/ Environmental |
Dimensions:
Standard 1U rackmount size Mounting: Desktop, wall-mount, rack-mount
Operating Temp: 0-45 °C Storage Temp: –10-60 °C Humidity: 10-90% RH
(operating), 5-95% RH (storage) |
|
Power / Supply |
Integrated AC power supply Non-PoE power consumption: Low
PoE version: 240W total PoE budget |
|
Front
/ Auxiliary Interfaces |
1
× Console port Reset pinhole Per-port LED indicators (link, activity, speed)
System status LEDs |
|
Warranty |
3 Years standard warranty |
* Product may vary with different Kit or
Version
Product Details
Grandstream GWN7802 20-Port Layer 2+
Managed Network Switch
The Grandstream GWN7802 is an
enterprise-grade 20-port Layer 2+ managed switch built for SMBs,
enterprises, and campus networks. It offers 16 Gigabit RJ45 ports
and 4 Gigabit SFP uplink ports, delivering high-performance, secure,
and flexible connectivity. With support for advanced VLANs, QoS, ACLs,
and enterprise security features, plus centralized cloud and on-premise
management via GWN.Cloud, the GWN7802 ensures efficient and reliable
network operations.
Key Features & Benefits
- 20 Ports Total
– 16 × Gigabit RJ45 ports, 4 × Gigabit SFP uplinks.
- High Switching Capacity – 40Gbps switching fabric for non-blocking
performance.
- Advanced L2+ & Security – Includes VLAN, ACLs, QoS, IGMP Snooping, 802.1X
authentication, and DoS defense.
- Enterprise-Grade Performance – Optimizes voice, video, and critical data traffic.
- Flexible Management
– Supports Web GUI, CLI, SNMP, and GWN.Cloud remote/cloud
management.
- Energy-Efficient & Durable – Fanless metal chassis with reliable long-term
operation.
Specifications
- Model:
GWN7802
- Type:
Layer 2+ Managed Gigabit Switch
- Ports:
16 × 10/100/1000Mbps RJ45, 4 × Gigabit SFP
- Switching Capacity:
40Gbps
- Forwarding Rate:
29.8 Mpps
- Management Options:
Web UI, CLI, SNMP, GWN.Cloud
- Security Features:
802.1X authentication, ACLs, DoS protection, VLAN, Storm Control
- Traffic Optimization:
QoS, IGMP Snooping, Link Aggregation
- Form Factor:
Rack-mountable metal chassis
- Color:
Black
Why Choose Grandstream GWN7802?
- Combines enterprise performance and advanced Layer
2+ features.
- Ensures secure, reliable, and scalable connectivity
for modern networks.
- Ideal for businesses, educational institutions, and
enterprise IT environments.
