Brand

Deepcool

Model

Deepcool CH260 WH

Series

Gaming

Type

Mini Tower

Technical Data

Supported Motherboard Type: Micro-ATX, Mini-ITX

Lighting Support (Front/Top/Side): No

Supported LED Strip: No

Fan / Light Controller: No

Back-Connect Supported: Yes

Graphics-Card Length: 388/413mm

Supported CPU Cooler: Air Cooler or Liquid Cooler

CPU Cooler Height: 174mm

PSU Length: 150mm

Cable Management Depth: Yes

Interfaces & Slots

Front/Top USB port: 2 x USB 3.0, 1 x USB Gen2 Type-C

Front/Top Audio Port: 1 x 3.5mm Combo

5.25 Inch Drive Bay: No

3.5 Inch Drive Bay: 1

2.5 Inch Drive Bay: 1

1.8 Inch Drive Bay: No

Expansion Slots: 4

Optical Drive Bay: No

Memory Card Slot: No

Cooling System Data

Cooling Fan (Built-In): No

Additional Fan Slot: 6

Pre-Installed Fan Size: Not Applicable

Supported Fan Size: 2 x 120mm (Front), 3 x 120mm/2 x 140mm (Top), 1 x 120mm (Rear).

Lighting Fan: No

Radiator Support Front/Top/Rear: Top:120/240/360mm, Rear:120mm

Radiator Support Max.: Up to 360mm

Power Data

Power Supply (Built-In): No

Power Supply Type: ATX PS2 (Not Included)

Power Supply: No

Approx. Power Consumption: 5W

Physical Atributes

Transparent Side Window: Yes

Case Windowed: Tempered Glass

Buttons: Power

Number of Buttons: 1

Material: ABS+SPCC+Tempered Glass

Dust Cover: Yes

Color: White

Dimensions: 312.5 x 225 x 438mm

Weight (Kg): 5.3 kg

Handle: No

Extra Data

Specialty

The Micro Form Factor CH260 comes with a tempered glass side panel to give your modern internal gears a show as the perforated top and front panels can be decked out with PIXEL rubber bits. The case also meets the rising demands for rear connector motherboards with a wider clearance of 29.6mm in the backplane, The CH260 provides multiple options in key components compatibility which can support full-size GPU up to 388mm in length or goes even longer to 413mm without front fan placement. ATX PS2 power supply can also fit into the case with a removable mounting bracket to free up space for easy cable management, The wraparound mesh panels and up to six 120mm fan placements effectively ensure cool air flows through the compact system and takes heat away. The maximum thermal hardware can go up to a 360mm AIO liquid cooler on top or a 174mm high tower heat sink on the CPU.

Warranty

1 Year Warranty For PSU, Fan, Button & Connectors Only (No Warranty For Casing Body / Structure)

* Product may vary with different Kit or Version
