Model

Antec AX90

Brand

Antec

Series

Gaming Desktop Case

Type

Mid Tower

Technical Data

Supported Motherboard Type: ATX, M-ATX, ITX

Supported LED Strip: No

Fan / Light Controller: No

Back-Connect Supported: No

Graphics-Card Length: <= 385mm

Supported CPU Cooler: Air Cooler or Liquid Cooler

CPU Cooler Height: <= 160mm

PSU Length: (Include cable) <= 220mm(with HDD), (Include cable) <= 410mm(without HDD)

Cable Management Depth: 23mm

Interfaces & Slots

Front/Top USB port: 2 x USB 2.0, 1 x USB 3.0

Front/Top Audio Port: 1 x Audio/ Mic

3.5 Inch Drive Bay: 2

2.5 Inch Drive Bay: 2

Expansion Slots: 7

Optical Drive Bay: No

Memory Card Slot: No

Cooling System Data

Cooling Fan (Built-In): 4

Additional Fan Slot: 7

Pre-Installed Fan Size: 120mm

Supported Fan Size: 120mm, 140mm

Lighting Fan: ARGB

Radiator Support Front/Top/Rear: Front - 120 / 140 / 240 / 280 / 360mm, Top - 120 / 140 / 240 / 280 / 360mm, Side - 120 / 240mm, Rear - 120mm,

Radiator Support Max: Up to 360mm

Power Data

Power Supply (Built-In): No

Power Supply Mounted: Bottom

Approx. Power Consumption: 30W

Physical Atributes

Transparent Side Window: Yes

Case Windowed: 4MM Tempered glass

Buttons: Power, Reset, LED Control Button

Number of Buttons: 3

Dust Cover: Front / Top / Bottom / Right Hand Side

Color: Black

Dimensions: 486 x 210 x 473mm

Weight (Kg): 6.77Kg (Net Weight), 7.93Kg (Gross Weight)

Handle: No

Extra Data

Others - Drive Bays: Expansion Slots - 7, 3.5`` / 2.5`` - 2 / 1, 2.5`` - 2, Fan : Front - 3 x 120mm / 3 x 140mm, Top - 3 x 120mm / 2 x 140mm, Power supply - 2 x 120mm, Side - 2 x 120mm, Rear - 1 x 120mm, Included Fan(s) - 3 x 120mm ARGB fans in front + 1x 120mm ARGB fan in rear.

Specialty - The AX90 features a unique mesh front panel design and excellent cooling performance. The full-view tempered glass side panel design allows you to show off your gaming configurations without any obstacles. 11 x 120mm fans can be installed simultaneously.

Warranty

No warranty

* Product may vary with different Kit or Version
