Afox IH610D4-MA5-V4 DDR4 Intel Motherboard
Key Specification
‣ Chipset - Intel H610
‣ Sockets Supported - LGA1700
‣ Supported CPU - Intel Core i9/ Core i7/ Core i5/ Core i3/ Pentium/
Celeron Processors
‣ Generation – 12th/13th/14th
‣ Memory Slot - 2
‣ Memory Max - 64GB
‣ Form Factor - Micro-ATX
Product Specification
|
Brand |
Afox |
|
Model |
Afox IH610D4-MA5-V4 |
|
Color |
Black |
|
CPU Data |
Chipset
Brand: Intel Chipset:
Intel H610 Sockets
Supported: LGA1700 Built-in
Processor: Unmentioned Supported
CPU: Intel Core i9/ Core i7/ Core i5/ Core i3/ Pentium/ Celeron Processors Generation
: 12th/13th/14th |
|
Memory Support |
Memory Type: DDR4 Memory MHz: 2133 / 2400 /2666 / 2800(O.C) / 3000(O.C)
/ 3200(O.C) MHz Memory Channel: Dual Memory Slot: 2 Memory Max: 64GB Optane Memory Support: Unmentioned |
|
Storage
Info |
Storage
Interface: Unmentioned M.2/SSD
Expansion Slot: 1 M.2/SSD
Expansion Slot Details 1 x M.2
(PCIe NVMe Gen3 x4 ) |
|
Graphics Info |
Graphics: Yes Graphics Chipset: Intel HD Graphics support Multi-GPU Support: Unmentioned PCI Express Slot: 1 x PCI Express x16 4.0
slot, 1 x PCI Express x1 slot |
|
Audio
& Video |
Audio
Chipset: Realtek 662 On Board Audio
Channel - 6 |
|
Network & Connectivity |
LAN Chipset: Realtek RTL8111 1000Mbps
Ethernet on board LAN Speed (Mbps): 10/100/1000Mbps WiFi: Unmentioned WiFi Technology: Unmentioned Bluetooth: Unmentioned |
|
Ports Data |
USB
Port: 2 x USB 3.0 Ports, 2 x USB 2.0 Ports VGA
Port: 1 DVI
Port: Unmentioned HDMI
Port: 1 DisplayPort
(DP): Unmentioned IDE
Port: Unmentioned SATA
Port: 3 x SATA Thunderbolt:
Unmentioned TPM
Port: Unmentioned |
|
Technical Data |
Back-Connect Design: Unmentioned Cable Management: Front Heatsink: Unmentioned FireWire: Unmentioned CrossFire Support: Unmentioned Sli Support: Unmentioned RGB Support: Unmentioned RGB Connector: Unmentioned Approx. Power Consumption: 60W Form Factor: Micro-ATX |
|
Compatibility |
Supported
Operating System: Windows 10 / 11 Compatible
Products: INTEL Socket 1700, support: Intel Core i9/ Core i7/ Core i5/ Core
i3/ Pentium/ Celeron Processors |
|
Warranty |
3 year |
|
* Product may vary with
different Kit or Version |
|
Product Details
Afox
IH610D4-MA5-V4 Micro-ATX Motherboard
The Afox IH610D4-MA5-V4 is a Micro-ATX
motherboard equipped with Intel H610 chipset, designed to support Intel's
12th, 13th, and 14th Gen Core processors. Offering DDR4 memory
support, it provides solid performance for budget and mid-range system builds.
Features
• Processor Compatibility:
Supports Intel Core i9, i7, i5, i3, Pentium, and Celeron processors with
LGA1700 socket.
• Chipset: Intel H610 chipset for reliable performance at an
entry-level price point.
• Memory Support:
Dual-channel DDR4 memory up to 3200 MHz (OC), with a maximum
capacity of 64GB.
• Audio:
Realtek 662 onboard audio codec with 6-channel audio support.
Storage
and Expansion
• M.2 Slot:
1 x M.2 PCIe NVMe Gen3 x4 slot for fast storage.
• SATA Ports:
3 x SATA 6Gb/s ports for additional storage options.
Graphics
and Expansion
• PCIe Slots:
1 x PCIe 4.0 x16 slot for a discrete graphics card.
1 x PCIe x1 slot for expansion cards.
• Integrated Graphics:
Supports Intel HD Graphics for basic visual tasks.
• Multi-GPU Support: Not mentioned.
Connectivity
Options
• USB Ports:
2 x USB 3.0
2 x USB 2.0
• Video Outputs:
1 x VGA
1 x HDMI
Network
and Audio
• LAN Chipset:
Realtek RTL8111 for 1000 Mbps Ethernet.
• LAN Speed: 10/100/1000 Mbps.
Design
and Build
• Form Factor: Micro-ATX
• Power Consumption: Approx. 60W
• Color Scheme: Black
Compatibility
• Supported Operating System: Windows 10 / Windows 11.
• Compatible Products: Compatible with Intel LGA1700 socket
processors (Core i9, i7, i5, i3, Pentium, Celeron, 12th/13th/14th Gen).
Warranty
Information
• Warranty: 3 years warranty.
Price
and Availability
The Afox IH610D4-MA5-V4
motherboard is available at Computer Village Agrabad, Chattogram, Bangladesh,
offering a solid foundation for building cost-effective Intel-based systems.
