Model

Acer V920B

Brand

Acer

Series

Gaming

Type

Mid Tower

Technical Data

Supported Motherboard Type: Micro-ATX, ITX

Supported LED Strip: No

Fan / Light Controller: No

Back-Connect Supported: No

Graphics-Card Length: 400mm

Supported CPU Cooler: Air Cooler or Liquid Cooler

CPU Cooler Height: 165mm

PSU Length: unmentioned

Cable Management Depth: unmentioned

Interfaces & Slots

Front/Top USB port: 1 x Type-C, 1 x USB 3.0, 1 x USB 2.0

Front/Top Audio Port: HD Audio

3.5 Inch Drive Bay: 2

2.5 Inch Drive Bay: 1

Expansion Slots: unmentioned

Optical Drive Bay: No

Memory Card Slot: No

Cooling System Data

Cooling Fan (Built-In): No

Additional Fan Slot: 9

Pre-Installed Fan Size: unmentioned

Supported Fan Size: Top: 3 x 120mm fan or 2x 140mm, M/B: 2 x 120mm, PSU Cover: 3 x 120mm, Rear: 1x 120mm

Lighting Fan: No

Radiator Support Front/Top/Rear: Top: 360/280mm, Rear: 120mm

Radiator Support Max: Up to 360mm

Power Data

Power Supply (Built-In): No

Power Supply Mounted: Bottom

Approx. Power Consumption: 5W

Physical Atributes

Transparent Side Window: Yes

Case Windowed: Tempered Glass Window

Buttons: Power

Number of Buttons: unmentioned

Dust Cover: unmentioned

Color: Black

Dimensions: 425 x 210 x 440mm

Weight (Kg): unmentioned

Handle: No

Extra Data

Others - NO SCREWS THROUGHOUT FULL VIEW CASE, VERTICAL COOLING DESIGN, More than just the bottom, Large Surrounding Air Intake Every side has the function of heat dissipation, Achieve all-round cooling effect. SUPER COMPATIBILITY, Supports large Micro ATX/ITX M/B, Hard Disk 2 HDD + 1 SSD OR 1 HDD + 2 SSD.

Specialty - 0.7MM THICK PLATE, Full glass protection Paired with ultra-thick panels, high-end quality, REASONABLE LINE HOLE DESIGN, Reasonable cable management space Unlimited PSU length, QUICK DISASSEMBLED STRUCTURE WITH T????????, Traditional technology, No screws Sturdy and stable, Convenient and aesthetically.

Warranty

No warranty

* Product may vary with different Kit or Version
